Mercury 6 SERIES

MANUAL STARTER
90-857138R1 MAY 2000 Page 8-9
5. Apply a small amount of 2-4-C Marine Lubricant in starter housing and install sheave.
6. Install ratchet pawls, and pawl springs into starter sheave as shown.
57226
57224
95
2-4-C With Teflon (92-825407A12)
95
a
a
b
b
a- Pawl Springs (2)
b- Ratchet Pawls (2)
7. Apply Loctite 271 to bolt. Torque bolt to 70 lb-in. (8 Nm).
57225
a
7
Loctite 271 (92-809820)
7
a- Bolt
