3. Place a block of wood between the gearcase and the propeller to hold the
propeller and remove the propeller nut.
4. Pull the propeller straight off the shaft. If the propeller is seized to the
shaft and cannot be removed, have the propeller removed by an
authorized dealer.
5. Coat the propeller shaft with Extreme Grease or 2‑4‑C with PTFE.
Tube Ref
No.
Description Where Used Part No.
Extreme Grease Propeller shaft 8M0071842
95
2-4-C with PTFE Propeller shaft 92-802859A 1
IMPORTANT: To prevent the propeller hub from corroding and seizing to the
propeller shaft, especially in saltwater, always apply a coat of the
recommended lubricant to the entire propeller shaft at the recommended
maintenance intervals and also each time the propeller is removed.
FLO-TORQ II PROPELLERS
1. Install the propeller onto the shaft with the supplied components as
shown.
MAINTENANCE
eng 75
