3.
Secure the locknut by bending three of the tabs into the grooves in the
drive sleeve adapter.
a -
Forward thrust washer
b -
Drive sleeve
c -
Propeller
d -
Drive sleeve adapter
e -
Locknut retainer
f -
Locknut
g -
Tabs bent into grooves
Description
Nm
lb‑in.
lb‑ft
Propeller nut
75
–
55.3
Spark Plug Inspection and Replacement
1.
Remove the spark plug leads. Pull the rubber boots off the spark plugs.
53781
c
d
e
f
a
b
g
45248
MAINTENANCE
eng
77
86
88
