Section 4 - Maintenance
Page 36 90-8M0113986 eng DECEMBER 2015
2. Remove the transmission oil drain plug and drain the transmission into a suitable container.
Transmission drain plug
3. Contain and dispose of the oil and oil waste according to applicable regulations.
4. Reinstall the transmission oil drain plug.
5. Tighten the drain plug to the specified torque.
Description
Nm lb‑in. lb‑ft
Transmission oil drain plug 17 150 –
6. Clean the exterior of the transmission around the oil filter assembly.
7. Loosen the retaining nut.
Transmission oil filter retaining nut
8. Remove the filter element.
9. Clean the oil filter element using the cleaning solvent.
Tube Ref No.
Description Where Used Part No.
Cleaning solvent Transmission filter element Obtain Locally
10. Lubricate the oil filter O‑rings.
Tube Ref No.
Description Where Used Part No.
80
SAE engine oil 30W Transmission filter element O-ring Obtain Locally
11. Reinstall the filter element.
