Section 4 - Maintenance
Page 32 90-8M0113986 eng DECEMBER 2015
3. Remove the dipstick and observe the oil level. The oil level must be between the marks on the dipstick. If necessary, add
oil. Refer to Filling.
Engine oil level markings
a - Dipstick
b - Minimum operating level
c - Full mark and maximum operating level
4. Install engine oil dipstick.
Filling
IMPORTANT: Do not overfill the engine with oil.
1. Remove the oil fill cap.
2.0L engine oil service
a - Engine cover with access panel removed
b - Engine oil fill cap
c - Engine oil dipstick
2. Add the specified oil to bring the oil level up to, but not over, the maximum mark on the dipstick.
Engine Oil
2.0L System Capacity Fluid Type Part Number
Engine oil (with filter) 5.2 L (5.5 US qt) 5W‑30 Full Synthetic TDI Engine Oil 92‑8M0069603
IMPORTANT: When filling the engine with oil, always use the dipstick to confirm the oil level.
3. Install the oil fill cap.
Changing Oil and Filter
Refer to the Maintenance Schedule for the change interval. Change the engine oil before placing the boat in storage.
IMPORTANT: Change the engine oil when the engine is warm from operation. Warm oil flows more freely, carrying away more
impurities. Use only recommended engine oil.
Engine Oil
2.0L System Capacity Fluid Type Part Number
Engine oil (with filter) 5.2 L (5.5 US qt) 5W‑30 Full Synthetic TDI Engine Oil 92‑8M0069603
1. Start the engine and allow it to warm up to normal operating temperature.
2. Stop the engine and allow the oil to drain into the oil pan for approximately five minutes.
3. Place a suitable container under the oil filter housing to capture any spilled oil. Use an appropriate socket to loosen the oil
filter cover.
4. Remove the drain plug on the oil filter housing and allow to drain into a suitable container.
5. Remove the oil filter cover and oil filter.
14624
