Section 4 - Maintenance
90-8M0113986 eng DECEMBER 2015 Page 39
6. Clean the exterior of the transmission around the fluid filter assembly.
7. Loosen the assembly nut, and rotate the securing tab in the direction shown.
a - Assembly nut
b - Securing tab
8. Remove the filter element.
a - Filter element
9. Clean the filter element with a mild cleaning solvent, obtained locally.
10. Lubricate the O‑rings with SAE Engine Oil 30W.
Tube Ref No.
Description Where Used Part No.
80
SAE Engine Oil 30W Transmission filter element O-ring Obtain Locally
