Mercury FourStroke 3.5 User Manual

Clamp/Swivel Bracket and Driveshaft Housing
90-8M0065421 NOVEMBER 2012 Page 5A-5
Cowling Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Top cowl
2 1 Cowl seal
3 1 Tilt handle
4 4 Washer
5 4 Lockwasher
6 4 Nut 6 53
7 1 Bottom cowl
8 1 Spark plug decal
9 1 Cowl latch
10 1 Collar
11 1 Bolt 6 53
12 4 Bolt 6 53
13 4 Washer
14 4 Collar
15 1 Fuel level decal
16 1 Oil level decal
17 1 Shift decal
18 1 Bushing
19 1 Auxiliary start rope
20 1 Notice This Side Up decal
21 1 Tool kit
22 1 Flushing plug
