Clamp/Swivel Bracket and Driveshaft Housing
90-8M0065421 NOVEMBER 2012 Page 5A-9
Driveshaft Housing Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Driveshaft housing
2 1 Plug
3 2 Dowel pin
4 1 Driveshaft housing gasket
5 7 Bolt 6 53
6 1 Flush plug 15 132
7 1 Gasket
8 1 Steering bracket
9 2 Bolt 15 132
10 1 Hose
11 1 Grommet
12 1 Stud
13 1 Stopper
14 2 Bolt 6 53
15 1 Grommet
16 1 Extension housing
17 1 Bushing
18 1 Bolt 11 97
19 1 Nut 6 53
20 1 Dowel pin
