Gear Housing
90-8M0065421 NOVEMBER 2012 Page 6A-7
Gear Housing (Propeller Shaft)
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Gear housing
2 1 Ball bearing
3 AR Shim (0.1) (0.15)
4 1 Forward gear
5 1 Cam follower
6 1 Spring
7 1 Clutch
8 1 Propeller shaft
9 1 Bearing carrier assembly
10 1 Bearing carrier
11 1 Ball bearing
12 1 Oil seal
13 1 O‑ring
14 2 Bolt 5.6 50
15 1 Shear pin (stainless steel)
16 1 Propeller
17 1 Cotter pin
