Gear Housing
90-8M0065421 NOVEMBER 2012 Page 6A-9
Shift Linkage Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Shift lever
2 1 Spring
3 1 Detent ball
4 1 Washer
5 2 O‑ring
6 1 Shift shaft lever
7 1 Screw (M5 x 12) 4 35
8 1 Upper shift shaft
9 1 Washer
10 1 Cotter pin
11 1 Joint
12 1 Bolt (M6 x 16) 6 53
13 1 O‑ring
14 1 Bushing
15 1 O‑ring
16 1 Lower shift shaft
17 1 Clutch cam
18 2 Pin
