Mercury FourStroke 3.5 - Page 186

Tiller Handle
90-8M0065421 NOVEMBER 2012 Page 7B-5
Tiller Handle Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Tiller handle
2 1 Grip
3 1 Rubber shaft
4 1 Bushing
5 1 Screw Drive tight
6 1 Bracket
7 1 Screw Drive tight
8 1 Throttle shaft friction device
9 1 Throttle friction knob As required
10 1 Spring
11 1 Bolt
12 1 Throttle shaft
13 1 Throttle decal
14 2 Rubber isolator bushing
15 1 Cover
16 2 Bolt 6 53
17 2 Throttle cable
18 1 Sleeve
19 1 Throttle drum
20 1 Throttle opener
21 1 Collar
22 1 Bolt 6 53
23 1 Washer
24 1 Throttle rod
25 2 Plastic bushing
