Powerhead
90-8M0065421 NOVEMBER 2012 Page 4A-7
Camshaft and Valve Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Camshaft assembly
2 1 Intake valve
3 1 Exhaust valve
4 1 Intake seal (black)
5 1 Exhaust seal (green)
6 2 Seat
7 2 Spring
8 2 Retainer
9 4 Keeper
10 2 Lifter
11 2 Push rod
12 1 Push rod plate
13 2 Pivot bolt 26 19.2
14 2 Rocker arm
15 2 Pivot
16 2 Nut 11 97
