Mercury FourStroke 3.5 User Manual

Powerhead
90-8M0065421 NOVEMBER 2012 Page 4A-9
Crankshaft, Piston, and Connecting Rod Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Crankshaft assembly
2 1 Ball bearing
3 1 Oil seal
4 1 Key
5 1 Connecting rod assembly
6 2 Screw
First torque 6 53
Final torque 11 97
7 1 Piston pin
8 2 Clip
9 1 Piston assembly
10 1 Ring set
11 1 Second piston ring
12 1 Oil ring assembly
