Powerhead
90-8M0065421 NOVEMBER 2012 Page 4A-13
Cylinder Block Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Cylinder block
2 3 Dowel pin
3 6 Bolt (M6 x 35) 11 97
4 2 Bolt (M6 x 75) 11 97
5 2 Washer
6 1 Recommended oil decal
7 1 Cylinder head cover
8 1 Cylinder head cover gasket
9 4 Bolt (M6 x 16) 6 53
10 4 Washer
11 1 Thermostat
12 1 Thermostat cap
13 1 Thermostat cap gasket
14 1 Clamp
15 2 Bolt (M6 x 30) 6 53
16 1 Spark plug
17 1 Slinger
18 1 Throttle cable bracket
19 1 Clamp
20 2 Bolt (M6 x 25) 6 53
21 1 Breather hose
22 2 Clamp
23 1 Breather chamber cover
24 1 Breather chamber cover gasket
25 2 Bolt (M6 x 16) 6 53
26 1 Fuel pump
27 2 Bolt 6 53
28 2 Clip
29 1 Hose from fuel shutoff valve
30 1 Hose to carburetor
31 2 Clip
To Next Page
