454 CID (7.4L) / 502 CID (8.2L)

SERVICE MANUAL NUMBER 23

Page 3A-11

90-861326--1 MARCH 1999

454 Mag / 502 Mag / 8.2L (Except 7.4L MPI L-29) Engine Specifications

(Continued)

ROLLER TAPPET CAMSHAFT

MODEL 454 MAG / 502 MAG / 8.2L

Lobe Lift ± 020 (0 051)

Exhaust .301 (7.645)

Lobe

Lift

020

051)

Intake .301 (7.645)

Duration at .050 In.(1.27mm)

Exhaust 227°

()

Cam Lift

Intake 211°

Journal Diameter 1.9482-1.9492 (49.485-49.509)

Journal Out Of Round .001 (0.025) Max

Camshaft Runout .002 (0.051) Max

Timing Chain Deflection

.375 (9.5) from taut position

[total .75 (19)]

FLYWHEEL

MODEL 454 MAG / 502 MAG / 8.2L

Runout .008 (0.203) Max

CYLINDER HEAD

MODEL 454 MAG / 502 MAG / 8.2L

Gasket Surface Flatness

.007 (0.178) Overall Maximum .003

(0.076) within a 6 in. (152 mm) Span
