7
Chapter 2: Motherboard Installation
* Please see Page 19 for more details about AGP Ultra slot.
ITEM LABEL COM PONENTS
1 CPU Socket LGA775 Socket for Intel Pentium 4/
Celeron D CPUs
2 PWRFAN Pow er fan connector
3 CPUFAN CPU Fan connector(4PIN)
4 IR1 Infrared header
5 ATX2 Standard 20-Pin ATX Pow er connector
6 FDD1 Floppy Disk Drive connector
7 IDE1 Primary IDE connector
8 IDE2 Secondary IDE connector
9DIMM1
DIMM3
184-pin DDR SDRAM sockets (Support
Dual-Channel DDR400)
10 DIMM2 184-pin DDR SDRAM sockets
11 JP1 Clear CMOS jumper
12 SATA1/2 Serial ATA connectors
13 SYSFAN System Fan connector
14 SPK1 Speaker header
15 PANEL1 Front Panel Sw itch/LED header
16 USB2/3 Front Panel USB headers
17 CNR1 CNR slot
18 CD1 Analog Audio Input header
19 AUDIO2 Front Panel Audio header
20 PCI 1-3 32-bit PCI slots
21 AGPRO
AGP Ultra slot
*
22 ATX3 Standard 4-Pin ATX Pow er connector
To Next Page
