30
Motherboard User’s Guide
OnBoard PCI IDE Controller
Use this item to enable or disable either or both of the onboard Primary and
Secondary IDE channels. There are four options: Disabled, Primary, Secondary
and Both.
Audio Device
This item enables or disables the AC’97 audio chip.
Ethernet Device
This item enables or disables the onboard Ethernet LAN.
MODEM Device
This item enables or disables the MC’97 modem chip.
OnBoard USB Function
Enable this item if you plan to use the USB ports on this motherboard.
USB Function For DOS
Enable this item if you plan to use the USB ports on this motherboard in a DOS
environment.
On-Chip Serial ATA
Use this item to disable or enable the S-ATA and IDE devices:
Serial ATA Port0/1 Mode
Use this item to decide the sequence of the Serial ATA devices.
Option Function
Disabled Disabled S-ATA Controller
Enhanced Mode Primary: 2 IDE Drives
Secondary: 2 IDE Drives
S-ATA: 2 S-ATA Drives
SATA Only Only Support S-ATA Mode
Combine Mode Primary: 2 IDE Drives
S-ATA: 2 S-ATA Drives
Note: If you need to install
Windows 98 or Windows ME,
please select “Combine Mode”.
