Identification
Engine Data Label Location
The engine data label is located on top of the electrical box.
a - Engine data label (not seen—on top of the
electrical box)
ZF Marine Transmissions
On the ZF Marine 63A 8° down‑angle and 63IV V‑drive transmissions, the transmission identification plate indicates gear ratio,
serial number, and model.
Typical ZF Marine down-angle transmission show (V-drive similar)
a - Transmission identification plate
a
7449
Section 1 - Getting to Know Your Power Package
90-8M0133568 eng JUNE 2017 Page 11
