Mercusys MR50G Quick Installation Guide

1
English
Connect the Hardware
According to the diagram in the opening chapter of this guide, follow the steps to connect the hardware.
If your internet connection is through an Ethernet cable from the wall instead of through a DSL/Cable/Satellite
modem, connect the Ethernet cable directly to the router’s WAN port, and follow Step 3 to complete the hardware
connection.
Step 1: Turn o the modem, and remove the backup battery if it has one.
Step 2: Connect the modem to the WAN port on your router with an Ethernet cable.
Step 3: Turn on the router, and wait for it to start.
Step 4: Turn on the modem.
Congure the Router
1. Connect your computer to the router (Wired or Wireless).
• Wired: Turn off the Wi-Fi on your computer and connect your computer to the router’s LAN port using an
Ethernet cable.
• Wireless: Find the product label on the router. Scan the QR code to join the preset 2.4 GHz network directly, or
use the default network names (SSIDs) to join the 2.4 GHz or 5 GHz network.
Note: Only certain models have QR codes.
2. Launch a web browser and enter http://mwlogin.net in the address bar. Create a password for future logins.
Note: If the login window does not appear, please refer to FAQ > Q1.
3. Follow the step-by-step instructions of Quick Setup to set up your internet connection and wireless network.
Enjoy the internet!
Note: If you have changed the SSID and wireless password during the conguration, use the new SSID and wireless password to join
the wireless network.

Mercusys MR50G Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1900 Mbit/s
WLAN data transfer rate (first band)	600 Mbit/s
WLAN data transfer rate (second band)	1300 Mbit/s
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (2.4 GHz)	1
Product type	Portable router
Product color	Black
Firewall security	IP and MAC Address Binding
Security algorithms	WPA-PSK, WPA2-PSK
Antennas quantity	6
Output current	1 A
Output voltage	12 V
Power source type	AC
Cables included	AC, LAN (RJ-45)
Package depth	267.5 mm
Package width	349.5 mm
Package height	80.5 mm
Package weight	760 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	157.2 mm
Width	175.6 mm
Height	45 mm
