INSTRUCTION MANUAL ME-104 16
• T COLD CENTER: time in tenth of second after heating during which the bar stay down
to allow the film to solidify. Aprox.: 10-40
• T HEAT LATS: time in tenth of second during which power is applied to the lateral
welding bar. This value will be reduced by the temperature compensation system (see below).
The amount of power can also be regulated in the control cabinet P2. Valor aprox.: 30-60
• WAITING CENTER: time in tenth of seconds that the mattress is waiting for the bar of
Module 2 to open. Aprox.: 5-10
• WAITING SIDES: time in tenth of seconds that the mattress is waiting for the bars of
Module 3 to open. Aprox.: 5-10
• TIME CUTTER CENTER: the first value is the time in tenth of seconds that the central
cutter will wait to activate (aprox 5). The second, the time during which the blade travel
trough the film in the central bar to separate the bag. After this time, the blade will back to its
position. Aprox.: 20-30
• TIME CUTTER S: the first value is the time in tenth of seconds that the lateral cutter
will wait to activate (aprox 5). The second, the time during which the blade travel trough the
film in the side bars to separate the rest of film. After this time, the blade will back to its
position. Aprox.: 20-30
• COMPENSATION: graphically shows the quantity to be subtracted from the
programmed time (T.HEAT) to compensate the actual temperature of the bars
• TEMP. SIMULATED: temperature of the welding bars calculated by the program. It
increased proportionally when heating and decrease exponentially the rest of the time. Is used
for introduce a corrective factor when the machine is used continuously, in order to avoid over
heating (see chap. 7)
• GAIN Q: value that increases the simulated temperature each tenth of second while
heating. Aprox.: 10
• GAIN F: value (center and sides) that decreases the simulated temperature while not
heating. It is apply each two seconds subtracting a division of the value (Temp/value) from the
simulated temperature. Aprox.: 8-15
TEST MENU:
