INSTRUCTION MANUAL ME-104 19
9. PART LIST
FASE Plano ID Cant Descripción
1 1 UCF205 16 Bearing flange type UCFL 205
1 2 UCP204 2 Bearing bridge type UCP 204
1 3 FC1 1 Photocell barrier emitter Telemecanique XUK-2AKSNL2T
1 4 PP1i 2 Polycarbonate door smoked 620x1120x8
1 5 BIS 4 Polypropylene door joint
1 6 FCBIS 2 Safety switch Telemecanique XCSPL591
1 7 FC0 1 Photocell barrier receiver Telemecanique XUK-5APANL2
1 8 PLACA1 2 Steel entrance plate
1 9 BANDA1 1 Conveyor belt PVC NAB-10ELBV 2250X3115
1 10 UCPA206 4 Bearing bridge type UCPA 206
1 11 M2 1 Motoreducer Bonfiglioli VF44 P1 20 P71 B14 B3, 0,37KW i=20
1 12 M1,4,5 3 Motoreducer Bonfiglioli VF44 P1 20 P71 B14, 0,37KW i=20
1 13 EV1,2,3 3 Electrovavle Univer 5/2 1/8 24 VDC G6250
1 14 CIL0 2 Cylinder Univer ISO 32 80 D.M
1 15 PP1d 1 Polycarbonate door smoked 620x1120x8
1 16 MANI 2 Door latch ref 5608
1 17 FC1 1 Photocell barrier receiver Telemecanique XUK-2APANL2R
1 18 GUB1 1 Steel plastic guide Ø50 x 3050
1 19 RU1R 2 Nylon wheel Ø200
1 20 D3,D4 2 Steel detector with inductive
1 21 S2,S7 2 Film tensor Ø20 with inductive
1 22 RUL 8 Roller for film Ø108 x 3050
1 23 FC2 1 Photocell barrier receiver XUM-5APANL2
1 24 CIL1 1 Cylinder Univer ISO 32 160 D.M
2 1 PP2d 2 Polycarbonate door smoked 765x880x8
2 2 CIL4 2 Cylinder Univer ISO 40 320 D.M
2 4 CP21 1 Guards sealing bar blade side
2 7 CP22 1 Guards sealing bar connections side
2 8 CIL3 2 Cylinder Univer ISO 63 400 D.M
2 9 CIL6 2 Cylinder Univer ISO 25 50
2 10 S3 1 Inductive detector Univer ISO63
2 11 PP2t 2 Polycarbonate door smoked 865x880x8
2 12 FCBIS 4 Safety switch Telemecanique XCSPL591
2 13 M7 1 Motoreducer Bonfiglioli VF44 P1 20 P71 B14 B3, 0,37KW i=20
2 14 ESET 4 Baquelite resistance terminal
2 15 NICR408 6 Resistance NiCr 4x0,8 (1m)
2 16 CELO2010 6 Celotex base spline 20x10 (1m)
2 17 NEOP2010 6 Neoprene self-adhesive 20x10 (1m)
2 18 BL 1 Trapezoidal blade (10 units)
2 19 PBL 1 Blade base
2 20 CIL5 1 Rodless cylinder Univer Ø16x3050 S1004163050
2 21 BANDA2 1 Conveyor belt PVC NSL-10ELAV 2250X3115
2 22 RU2L 2 Nylon wheel Ø200
2 23 UCPA206 4 Bearing bridge type UCP 206
2 24 UCFL205 4 Bearing flange type UCFL 205
3 1 PLACA3F 1 Steel fix ramp
3 2 PRT 2 Polyurethane plate for waste
3 3 BANDA3 1 Conveyor belt PVC NSL-10ELAV 2250X4035 (4635 p/EXTRA WIDE)
3 4 PLACA3M 1 Steel movable ramp
