INSTRUCTION MANUAL ME-104 20
3 5 M3 1 Motoreducer Bonfiglioli VF44 P1 20 P71 B14 B3, 0,37KW i=20
3 6 S4 1 Inductive detector RESCHNER M12 4mm 30VDC
3 7 LGR15 2 Lineal guide HIWIN LGR15 w/bearing LGH15
3 8,9 PP3 4 Polycarbonate door smoked 910x880x8
3 10 PM3Z14 4 Rotative gear M3 Z=14
3 11 CP3 2 Guards sealing bar lateral side
3 12 CIL11 4 Cylinder Univer ISO 40 400 D.M
3 13 CIL7 4 Cylinder Univer ISO 40 320 D.M
3 14 UCPA206 4 Bearing bridge type UCPA 206
3 15 M6 1 Motoreducer Bonfiglioli VF44 P1 20 P71 B14 B3, 0,37KW i=20
3 16 S5 1 Switch detector with Ø45 wheel
