Meridian DSP33 - Specification and Accessories

Introduction
7
Specification
Digital inputs 2 x cable, 75Ω, IEC958, 32-96kHz. FIFO
locks at 44.1, 48, 88.2, or 96kHz ±
150ppm.
1 x digital output cable, 75Ω, IEC958,
providing a copy of the selected input.
Processing 1 x Motorola 56364 running at 100MHz.
Power amplifiers Low feedback complementary bipolar
design, with output-stage error
correction and twin loop design.
Treble: 50W RMS.
Bass: 85W RMS.
Digital to analogue 24-bit Delta-Sigma.
conversion
Distortion Typically <0.01%, or <0.05% up
to full power at all frequencies.
Noise and hum <-95dBr at all volume settings.
Acoustic output Typically >104dB spl @ 1m.
Acoustic noise <15dB spl @ 1m.
Frequency response In room response within 3dB, 60Hz-
20kHz, lower at moderate volumes.
Crossover Linear-phase ±30º at 2.3kHz.
Drive units Woofers: 2 x 125mm (5") carbon fibre
custom drivers, cast alloy chassis.
Tweeter: 1 x 25mm (1") aluminium dome
neodymium magnet, with protective grille.
Control 2 x Meridian Comms.
9-pin D connector for RS232 PC setup
and control, null modem, 9600 baud,
2N1, no handshake.
Cabinet Extruded and cast aluminium with
bracing elements.
Dimensions 150mm x 395mm x 210mm
(5.9" x 15.6" x 8.3") (W x H x D).
Weight 9.5kg (21lb) each.
Power 100-125; 200-250V AC 50-60Hz.
6VA idle; 200VA max.
Meridian Audio reserves the right to amend product
specifications at any time.
Specification and accessories
