Merrychef eikon e2s User Manual

4 Moving the appliance
eikon e2s Installation and Operating Manual CE 41
4.2 Moving the appliance to the installation location
Space required for conveying the appliance
Make sure that there is enough width and height along the entire route used for conveying the appliance
to ensure it can get through to its installation location.
The table below shows the dimensions of the appliance including packaging, which are needed to
determine the minimum doorway dimensions required to allow the appliance to be brought to its in-
stallation location:
Minimum door opening
Width
[in]
21.1
[mm]
535
Height
[in]
33.5
[mm]
850
Depth
[in]
35.3
[mm]
895
Load bearing capability for conveying the appliance
Provide moving equipment that is rated capable of carrying the load.
Refer to the weight of the appliances including packaging to determine the minimum working load limit of
handling equipment; see ‘Dimensions and weights' on page 108.
Moving the appliance to the installation location
Please observe the following points when conveying the appliance:
 Always move the appliance on a pallet.
 Always move the appliance in an upright position.
 Move the appliance slowly and carefully, and secure it against tipping over.
 Make sure that you do not knock against things with the appliance.
 Avoid moving the appliance along uneven routes or up or down slopes/steps.
 Do not lift the oven by the handle but always use the hand lifting points.

Merrychef eikon e2s Specifications

General

Microwave Power	1000 W
Convection Power	2200 W
Control Type	Touchscreen
Ventless Cooking	Yes
Cooking Technology	Microwave, Convection, Impingement
Warranty	1 year parts and labor
Power Supply	208-240V, 50/60Hz
Power Consumption	3200W
Cooking Modes	Microwave, Convection
Temperature Range	100°C to 275°C
