Merrychef eikon e2s User Manual

5 Setting up the appliance
eikon e2s Installation and Operating Manual CE 45
Minimum space required
The following diagram and table show the space required for the appliance for different installation and
operating situations. They also show the minimum horizontal distances from adjacent walls and sur-
faces. The safety clearance on the top must always be complied with.
Meaning
Space required
A
Safety clearance from the top
[in]
2
[mm]
50
B
Depth requirement, appliance door open at 90°
[in]
12.2
[mm]
310
Safety clearance on left-/right-hand side / at rear
[in]
0
[mm]
0

Merrychef eikon e2s Specifications

General

Microwave Power	1000 W
Convection Power	2200 W
Control Type	Touchscreen
Ventless Cooking	Yes
Cooking Technology	Microwave, Convection, Impingement
Warranty	1 year parts and labor
Power Supply	208-240V, 50/60Hz
Power Consumption	3200W
Cooking Modes	Microwave, Convection
Temperature Range	100°C to 275°C
