SPARE PARTS22
Parts list & recommended minimum stock holding & Service Kits
Exploded
BOM No.
Part
Number
Description
Qty
Per
Oven
Unit
1-10
Ovens
11-50
Ovens
51-100
Ovens
1st Aid/
To Go
Box
Service
Centre
Kit
1 105005 M3 CAGE NUT 10 EA 10 30 60
2 30Z0217 FUSE 1in 10A HRC 2 EA 2 6 12 2 4
3 30Z0231 FUSEHOLDER 1in (13A) 3 EA 1 2 4 1 2
4 30Z0240 MICROSWITCH 2 EA 2 6 12 2 4
5 30Z0394 FUSE 1in 7A HRC 1 EA 2 6 12 2 4
6 30Z0503 SWITCH ON/OFF ROCKER DPST 1 EA 1 3 6 1 1
7 30Z1177 20 AMP LITTLEFUSE FLM020 2 EA 2 6 12 2 4
8 30Z1178 30A FUSE HOLDER 2 EA 1 3 6 1 2
9 30Z1298 CAPACITOR - MOTOR START (COOLING) 1 EA 2 6 12 1 2
10 30Z1340 FILTER 16A SCREW MOUNT 5 EA 2 6 12 1 4
11 30Z1415 MAGNETRON 2M303H 2 EA 1 3 6 1 2
12 30Z1425 LV TRANSFORMER 1 EA 1 3 6 1 2
13 30Z1427 MAGNETRON OVERHEAT STAT 2 EA 1 3 6 1 1
14 30Z1430 MICROSWITCH (LARGE) 1 EA 1 3 6 1 1
15 30Z1439 RELAY 12V OMRON 2 EA 1 3 6 1 2
16 30Z5000 SMART RELAY BOARD SRB 1 EA 1 3 6 1
17 30Z5002 TOUCH SCREEN & PCB 1 EA 1 3 6 1
18 31Z0115 INSULATOR PAD 2 EA 2 6 12
19 31Z0166 3-WAY TERMINAL BLOCK 1 EA 2 6 12 1
20 31Z0186 SILASTIC BLACK (DOOR SEAL) TUBE 1 3 6 1 1
21 31Z0477 4 WAY MAINS TERMINAL BLOCK 1 EA 1 3 6 1
22 31Z0600 USB ADAPTOR MODULE 1 EA 1 3 6 1
23 31Z0620 BTS UI SRB CABLE (WHITE) 1 EA 1 3 6 1 1
24 31Z1255 PG21 CABLE GLAND BLACK 1 EA 1 3 6
25 31Z1256 PG21 CABLE GLAND NUT 1 EA 1 3 6
26 31Z1259 SHEET COVER CAP 12MM DIA 4 EA 4 12 24
27 31Z1307 ETHERNET HOLE PLUG 1 EA 1 3 6
28 31Z3154 M4x6 SET SCREW S/S A2 (IMPINGER) 2 EA 1 3 6 1
29 32Z1066 DOOR HANDLE 1 EA 1 3 6
30 32Z4028 HALF SIZE GASTRONOM DISH 1 EA 1 3 6
31 32Z7062 PERSONALITY MODULE SRB e4 1 EA 1 3 6 1
32 32Z7065 PERSONALITY MODULE BTS e4 1 EA 1 3 6 1
33 DR0005 4 COIL DUAL HEAT ELEMENT 3.2kW 1 EA 1 3 6 1
34 DR0006 REED SWITCH 1 EA 1 3 6 1 1
35 DR0007 MERRYCHEF BADGE 1 EA 1 3 6
36 DR0008 MERRYCHEF BADGE SLIDER 1 EA 1 3 6
37 DR0009 MERRYCHEF BADGE GUIDE 1 EA 1 3 6
38 DR0010 MERRYCHEF BADGE SEAL 1 EA
1 3 6
39 DR0011 TOUCHSCREEN OVERLAY 1 EA 2 6 12 1
40 DR0021 HARMONISED SPEAKER 1 EA 1 3 6 1
41 DR0043 OVERHEAT STAT LARGE 1 EA 1 3 6 1 1
42 DV0061 IMPINGER THUMB NUT 2 EA 2 6 12 1
43 DV0168VIT DOOR CHOKE PRESSED (VITREOUS) 1 EA 0 1 2
44 DV0187 TOP PANEL (PRESSED) 1 EA 0 1 2
45 DV0202 CERAMIC PLATE RETAINER 4 EA 4 12 24 4
46 DV0239 IMPINGER FIXING - FAST THREAD 2 EA 1 3 6 1
47 DV0275 RACK V3 1 EA 1 3 6
48 SA3113 DOOR SEAL HT 1 EA 1 3 6 1 1
49 DV0366 GREASE FILTER HOUSING (EASY OUT) 1 EA 1 3 6
50 DV0370 LOWER IMPINGER HANDLE 1 EA 1 3 6 1
51 DV0397 CAST REAR DUCTING RH 1 EA 0 1 2
52 DV0403 CAST REAR DUCTING LH 1 EA 0 1 2
53 DV0437 LOWER FASCIA FINISHED 1 EA 0 1 2
54 DV0452 CAPACITOR CLIP 2 EA 2 6 12
55 DV0467 SIDE PANEL RH 1 EA 0 1 2
56 DV0468 SIDE PANEL LH 1 EA 0 1 2
57 DV0661 THERMOCOUPLE (OVEN) 1 EA 1 3 6 1 1
58 DV0666 STIRRER COVER - CERAMIC 2 EA 2 6 12 2 2
59 DV0692 SEAL - CERAMIC COVER 2 EA 2 6 12 2 2
60 DV0700 DOOR SKIN 1 EA 0 1 2
61 MC3175 OVEN TRAY - SQUARE 1 EA 1 3 6
62 30Z5008 DIODE PCB ASSY 2 EA 2 6 12 2 2
63 PSA111 DOOR ASSY (PRESSED) 1 EA 0 1 2
64 PSA1122 COOLING FAN SUB-ASSEMBLY 1 EA 1 3 6 1
65 PSA1180 HOT AIR MOTOR ASSY 1 EA 1 3 6 1
