Merrychef eikon e4 Service & Parts Manual

48
Service & Parts Manual original Instructions
Part Number 32Z3810GB
Issue 1
FAULT FINDING
Error
Code
Error Condition Description Trigger Possible Causes
Error
Level
System
Response
E 110
SRB version
conict
SRB rmware version
incompatible with
BTS version
The BTS has
found that
the rmware
running the SRB
is not supported.
Firmware update
has been carried
out to the BTS
and the SRB has
not been updated
to match.
Critical
Display error
message until
system is
power cycled.
E 111
Cavity sensor
error
Cavity sensor broken
/ unplugged
The controller is
reading an open
circuit across the
thermocouple
input
The
thermocouple
is not
connected. The
thermocouple
is broken open
circuit. Failed SRB.
Critical
Display error
message until
system is
power cycled.
N/A
Oven door open
longer than 1 min.
Oven door open.
Oven inoperable.
Break in
switched feed
on SRB
Door left open.
Failed door
switch/s or SRB.
Faulty wiring or
connection.
Warning
Display
warning
message until
door is closed.
N/A Air Filter removed
Air lter not tted.
Oven inoperable.
Filter not tted.
Failed reed
switch/s or SRB.
Faulty wiring or
connection.
Warning
Display error
message until
lter replaced.
