Quick Start Guide. Original instructions.
Part Number 32Z3848 GB Issue 3
MAIN FEATURES
1 ON/OFF SWITCH
When switched ON the easyToUCH® screen illuminates the oven
controls.
NOTE: Turning this switch OFF does not isolate the oven from the
electricity supply.
2 easyToUCH® SCREEN CONTROL PANEL
See ‘OPERATION & CONTROLS’ for details.
3 RATING PLATE
Located on the rear panel of the oven states the serial number,
model type & electrical specications.
4 USB port/Merrychef badge
A USB socket located under the ‘Merrychef’ logo allows changes to
programs stored on the oven (See USB MenuConnect® User Manual,
and ‘OPERATION & CONTROLS’ section of this manual, for details of
updating oven programs).
5 AIR OUTLETS
Air used to cool internal components and steam from the cavity
escape through the air outlet vents located on the rear of the oven.
The air outlets must be kept free from obstruction and they will not
allow microwave energy to escape into the environment.
6 AIR INLET FILTER
The air lter situated at the lower front of the oven is part of the
ventilation system and must be kept free of obstruction and cleaned
daily as described under ‘CLEANING & MAINTENANCE’.
NOTE: The oven will not operate without the air lter tted.
7 DOOR HANDLE
This is a rigid bar which is pulled downwards and away from the oven
to open.
8 OVEN DOOR
This is a precision-made energy barrier with three microwave
safety interlocks. The door must be kept clean (see ‘CLEANING &
MAINTENANCE’) and should NOT be used to support heavy objects.
9 DOOR SEALS
These ensure a tight seal around the door. They should be kept clean
and checked regularly for signs of damage. At the rst sign of wear
they should be replaced by a Merrychef approved Service Agent.
10 CONVECTION FAN, AIR DIFFUSER & CATALYTIC CONVERTOR
The convection fan must be kept clean and free of debris. Great
care should be taken when cleaning this area of the oven noting
the dierent oven requirements shown under ‘CLEANING &
MAINTENANCE’ in this manual.
11 OVEN CAVITY
The oven cavity is constructed from stainless steel and must be kept
clean by following the cleaning instructions in the ‘CLEANING &
MAINTENANCE’ section of this manual.
