74 Meru Access Point Installation Guide © 2010 Meru Networks, Inc.
Installation Requirements
AP150 Installation Items
You need the tools listed below.
Installation Type Consumable Items Required
Horizontal mounting None
Vertical mounting over a wall stud
 Two #6 x 2" wood screws for a wood stud; or
 Two #6 x 1½” metal screws for a metal stud
 Mounting bracket
Vertical mounting on sheetrock
 Two #6 x 1" screws
 Two #4-6 x 7/8” ribbed plastic wall anchors
 Mounting bracket
Horizontal mounting below a
hanging ceiling
 Two caddy fasteners
 Two plastic spacers
 Two keps nuts (with attached lock washer)
 Mounting bracket
Mounting above a ceiling tile
 Two T -r ail c li ps
 One T-box hanger
 One bracket mounting clip
 Mounting bracket
