Checking LED Activity
© 2010 Meru Networks, Inc. Installing AP200 69
AP200 LED Descriptions
AP200 Controller Status Information
LED Function
RF 2
The status LED for Radio 2 is a follows:
off—no radio present
yellow—radio initializing
red—radio failure
solid green—radio OK
blinking green—radio activity
RF 1
The status LED for Radio 1 is a follows:
off—no radio present
yellow—radio initializing
red—radio failure
solid green—radio OK
blinking green—radio activity
Status AP-Controller operational status (see Table )
Power green—presence of power
State Interpretation AP200 LED Cycle
Attempting to
discover Controller
In the process of discovering the
controller. The AP is connected but not
associated with the controller. If the AP
does not associate with the controller
after a period of time, verify that the
connection between the AP and the
switch or the switch and the controller
is unbroken.
Green/Red/Blue/R
ed
Connected Normal operation without security.
Blue/Blue/Blue/Re
d
Blue/Blue/Blue/Re
d, for 2 seconds.
Authenticated Normal operation with security. Blue blink
a
