Meru Networks AP300 User Manual

Installing the Access Points
© 2010 Meru Networks, Inc. Installing AP200 65
Figure 23: Box Hanger Mounting Bracket Holes
4. Attach the U-joint of the clip to the T-bar and snap in place (see Figure 24).
Figure 24: Attaching the Mounting Bracket to the Box Hanger
.
5. Pass the long end clip through the large center hole to the underside of the
mounting bracket clip and then attach the bracket to the clip using the supplied
screw (see Figure 24 for orientation).
Mounting bracket holes
00101
00104
