Das Lagersystem
27
Spannverstrebungen, Doppelregale : L = 1000 / 1300 mm
Stabilising supports, double rack : L = 1000 / 1300 mm
Entretoises de tension, rayons double : L = 1000 / 1300 mm
L
L
L
GR
AR
AR
AR
AR
GR = Grundregal / Basic rack / Rayonnage de base
AR = Anbauregal / Rack extension / Rayonnage rapporté
2000 x 1000 / 1300
X
GR AR
L
