Saw blade not installed properly:
Install saw blade properly (see chapter 10.
"Maintenance").
Turntable hard to turn
Chips under turntable:
remove chips.
KGSV 72 Xact SYM: Angle setting hard to
effect when moving the table halves (9)
Chips under turntable:
remove chips. The space under the turntable is
accessible through openings on the rear
Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
U=mains voltage
I=rated power
F =min. fuse protection
P
1
=rated input power
IP =protection class
n
0
=No-load speed
v
0
=max. cutting speed
D =saw blade diameter (outer)
d = saw blade hole (inside)
b = max. tooth width of the saw blade
a
1
=angle range saw head adjustment
a
2
=angle range turntable
a
SYM1
=inside angle at the guide system
a
SYM2
=outside angle at the guide system
A =dimensions (lxwxh)
m=weight
Requirements for chip and dust extraction unit:
D
1
=connection diameter of the extraction
nozzle
D
2
=minimum air throughput
D
3
=minimum negative pressure at extraction
nozzle
D
4
=minimum air speed at extraction nozzle
Maximum cross-section of workpiece, see table
on page 4.
~ AC Power
Machine in protection class II
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
Emission values
These values make it possible to assess the
emissions from the power tool and to compare
different power tools. The actual load may be
higher or lower depending on the operating
conditions, the condition of the power tool or the
accessories. Please allow for breaks and periods
when the load is lower for assessment purposes.
Arrange protective measures for the user e.g.
organisational measures based on the adjusted
estimates.
Typical A-effective perceived sound levels
:
L
pA
=sound-pressure level
L
WA
=acoustic power level
K
pA
, K
WA
= uncertainty
Wear ear protectors!
