ENGLISHen
20
current supply is restored following an
interruption, the machine does not start up:
• Switch the machine off and back on again.
No mains voltage
• Check cables, plug, outlet and
mains fuse.
Motor overheated, e.g. by a blunt saw blade or
chip build-up in the chip case:
• Remove cause for overheating, let cool off for a
few minutes. Then restart machine.
Speed is not reached
Overload protection: There is a MAJOR reduction
in load speed.
• The motor temperature is too high! Allow the
machine to run at idle speed until it has cooled
down.
Overload protection: There is a SLIGHT reduction
in load speed.
• The machine is overloaded. Reduce the load
before continuing to work.
Specified maximum no-load speed is not reached
- motor not receiving sufficient mains voltage:
• Use a shorter feed line or cable with larger cross
section
( 1.5 mm
2
).
• Have power supply checked by a qualified
electrician.
Loss of cutting performance
Saw blade blunt (possibly tempering marks on
blade body):
• Replace saw blade (see chapter 10.
Maintenance).
Chip ejection blocked
No dust collector connected or suction capacity
insufficient:
• Connect extraction system or increase suction
capacity (air speed 20 m/sec at chip ejection
tube).
Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating
instructions.
Saw blade Power Cut
Order no.: 6.28025
- For rough and medium-fine cuts with rapid
movement and limited power requirements
- Good cutting results for longitudinal cuts in solid
wood
Saw blade Precision Cut
Order no.: 6.28059
- Very wide range of applications in wood
processing
- For very good, clean cutting results for straight
and cross cuts in soft and hard wood
- Well suited for hard wood and plywood, untreated
chipboards, coated or veneered, MDF, composite
materials
Circular saw blade Multi Cut
Order no.: 6.28093
- Universal use for demanding materials
- When high cutting quality is required, e.g.
laminate, plastic, thin-walled aluminium, copper,
and brass profiles
- Ideally suited for many applications in interior
construction
- Perfect cutting results also for cross cuts in solid
wood, uncoated, coated or veneered chip board,
MDF
Push stick (as replacement)
Order no.: 343433180
For a complete range of accessories, see
www.metabo.com or the catalogue.
Danger!
For safety reasons, repairs to power tools
must be carried out by qualified electricians
only using original spare parts!
A defective mains cable must be replaced only
with a special, original mains cable from Metabo
available from the Metabo service.
Please contact your Metabo service centre if you
have Metabo devices that require repairs. See
www.metabo.com for addresses.
You can download a list of spare parts from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of
disused machines, packaging and accessories.
Packaging materials must be disposed of
according to their labelling in accordance with
municipal guidelines. Further information can be
found at www.metabo.com in the “Service”
section.
Only for EU countries: never dispose of
power tools in your household waste!
According to European Directive 2012/19/
EU on Waste from Electric and Electronic
Equipment and implementation in national law,
used power tools must be collected separately
and recycled in an environmentally-friendly
manner.
Explanatory notes on the specifications on page 3.
Subject to change in accordance with technical
progress.
U = mains voltage (~ alternating current)
P
1
=Rated input power
I=Rated current
F = Min. fuse protection
IP = protection class
n
0
= No-load speed
v
0
= Max. cutting speed
W = thickness of splitting wedge
D = saw blade diameter (outer)
d=saw blade hole (inside)
b = cutting width
a = max. base body thickness of the saw
blade
T
90°
= cutting height with vertical saw blade
T
45°
= cutting height with saw blade inclination
of 45°
S
x°
= saw blade swivel range
L
p
= max. cutting width with ripping fence
L
W
= max. cross-section with angle guide
A
1
= dimensions without machine stand
(lxwxh)
S
L
=length of saw table
S
B
= width of saw table
m = machine weight
Measured values determined in conformity with
EN 62841.
~ AC power
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
Emission values
These values make it possible to assess the
emissions from the power tool and to compare
different power tools. The actual load may be
higher or lower depending on the operating
conditions, the condition of the power tool or the
accessories. Please allow for breaks and periods
when the load is lower for assessment purposes.
Arrange protective measures for the user, such as
organisational measures based on the adjusted
estimates.
Typical A-effective perceived sound levels
:
L
pa
= Sound-pressure level
L
WA
= Acoustic power level
K
pA
, K
WA
=Uncertainty
Wear ear protectors!
