95-6511 DASH DISASSEMBLY
JEEP COMMANDER/GRAND CHEROKEE 2008-2010
A
B
POWER
OUTLET
C
12
3
4
5
6 AUX
AUX
SET
VOLUME
PUSH ON
PUSH AUDIO/SELECT
AM
FM
DISC
LIST
MUSIC
TYPE
SEL;ECT
TUNE/SCROLL
SEEKSEEK
SCAN
TIME INFO RW
FF
U
D
10
1
Unsnap and remove the larger trim
around the console shifter. ( Figure B)
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
3
Unsnap and remove the small trim
around the console shifer. (
Figure A)
2
Unsnap and remove the dash panel
from around the radio (including cli-
mate controls). (
Figure D)
5
Remove (4) Phillips screws securing
the radio. Unplug and remove radio.
6
Remove one Phillips screw from
inside the small storage pocket in the
lower dash, between the power outl-
lets. ( Figure C)
4
Continue to kit assembly.
