95-6511 DASH DISASSEMBLY
JEEP WRANGLER 2007-2010
A
1
2
3
4 5
6
B
11
1
Remove (2) Phillips screws exposed
behind lower center panel. (
Figure A)
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
3
Unclip and remove the lower center
trim below a/c controls. (
Figure A)
2
Remove (2) Phillips screws exposed
behind upper center panel. (
Figure A)
5
Unclip and remove entire panel sur-
rounding radio and climate controls,
including a/c vents.
6
Remove (4) 7MM screws securing
radio. Unplug and remove radio.
(
Figure B)
7
Unclip and remove the upper center
trim starting towards the rear of the
panel. (
Figure A)
4
Continue to kit assembly.
NOTE: The top of the metal bracket in
the sub dash will need to be cut to
allow for the clearance of the Double
DIN radio’s chassis.
