95-6518B
Kit Assembly
Double DIN radio provisions
Note: For proper orientation, the
locating tabs on the Radio Housing
are more to the top of the kit than
bottom. (Figure A
1. Rotate the brackets into the
radio housing. (Figure B)
2. Slide the radio into the bracket/
radio housing assembly and secure
using the screws supplied with the
radio. (Figure C)
3. Locate the factory wiring harness
and antenna plug in the dash.
Metra recommends using the
proper mating adapters from
Metra and/or AXXESS.
4. Reassemble dash in reverse order
of disassembly.
(Figure C)(Figure B)
(Figure A)
Top of housing
