DASH DISASSEMBLY
1. Unclip and remove the trim panel
surrounding the factory radio. (Figure A)
2. Remove (4) T-20 Torx Screws securing
the radio. (Figure B)
3. Unplug and remove the radio.
4. Cut shaded area at the top of the radio
cavity. (Figure C)
Continue to Kit Assembly
(Figure A)
(Figure B)
(Figure C)
Remove
shaded
area
