2
1. Open the power outlet cover and
remove (1) Phillips screw. (Figure A)
Note: No screw present for year 2000
models.
2. Unclip, unplug and remove the
dashboard trim panel. (Figure A)
3. Remove (2) 3/8” hex-head screws
securing the radio to the dash. Slide the
radio out, then unplug and remove
Continue to Kit Preparation
(Figure B)
(Figure A) (Figure A)
DASH DISASSEMBLY
KIT PREPARATION
1. Place the cut template over the
dashboard trim panel. (Figure A)
2. Using a scribe tool, score the area in the
radio section to be cut. (Figure B)
3. Remove the cut template, then cut the
scored area with a cutting tool.
Continued on the next page
Remove shaded area
