Metra Electronics 95-7309 - Hyundai Sonata 1995-1998 Dash Removal

Dash Disassembly 95-7309
Hyundai Sonata 1995-1998
1. Unclip and remove trim panel around
the shifter. (Figure A)
2. Remove (1) Phillips screw at bottom of
radio trim panel.
3. Unclip and remove radio trim panel.
(Figure B)
4. Remove (4) Phillips screws securing the
radio.
Continue to kit assembly
(Figure A)
(Figure B)
