Dash Disassembly 95-7309
Hyundai Sonata 1999-2001
1. Unclip and remove the trim panel in
front of the shift lever and remove (2)
Phillips screws exposed underneath.
(Figure A)
2. Unclip and remove the shift lever trim
panel. (Figure A)
3. Remove (2) Phillips screws at bottom
of radio trim panel.
4. Unclip and remove radio trim panel.
(Figure B)
5. Remove (4) Phillips screws securing
the radio.
Continue to kit assembly
B
A
(Figure A)
(Figure B)
