Dash Disassembly 95-7309
Hyundai Santa Fe 2001-2006
1. Remove the ashtray and the (2) Phillips
screws exposed in the cavity. (Figure A)
2. Unclip and remove trim panel with
climate controls. (Figure B)
3. Remove (2) Phillips screws facing up at
bottom of radio trim panel. (Figure C)
4. Unclip and remove the radio trim panel.
(Figure D)
5. Remove (4) Phillips screws securing
the radio.
Continue to kit assembly
(Figure B)
(Figure D)
(Figure C)
(Figure A)
To Next Page
