Metra Electronics 95-7313 - Kit Assembly; Double DIN Head Unit Provision

5
95-7313
Slide the appropriate bracket into
the trim plate aligning the holes in
the trim plate to the clips on the
bracket.
(Figure A)
1
A
C
Slide the DDIN radio unit into the
trim plate bracket assembly and
secure the unit to the kit using the
screws supplied with the head unit.
(Figure B)
2
DOUBLE DIN HEAD UNIT PROVISION
CUT
CUT
B
KIT ASSEMBLY
NOTE: For the 2003-2008 Hyundai
Tiburon applications you will need to
cut and remove the bottom mount-
ing tabs on the DDIN brackets.
(Figure C)
