Metra Electronics 95-7313 - Stacked ISO DIN Head Unit Provision

6
95-7313
KIT ASSEMBLY
1
Slide the stacked ISO DIN units into
the trim plate bracket assembly and
secure the unit to the kit using the
screws supplied with the head unit.
(Figure B)
2
STACKED ISO DIN HEAD UNIT PROVISION
A
B
Slide the appropriate bracket into
the trim plate aligning the holes in
the trim plate to the clips on the
bracket.
(Figure A)
C
CUT
CUT
NOTE: For the 2003-2008 Hyundai Tiburon
applications you will need to cut and
remove the bottom mounting tabs on the
DDIN brackets.
(Figure C)
