95-7322 DASH DISASSEMBLY
HYUNDAI AZERA 2006-2010
Remove (3) Phillips screws from the
top of the radio trim panel.
(Figure D)
5
Remove (2) Phillips screws from
under radio trim panel.
(Figure E)
6
Unclip and remove the entire trim
panel surrounding the radio.
(Figure F)
7
Remove (4) Phillips screws securing
the radio. Unplug and remove radio.
(Figure G)
8
Continue to kit assembly.
