95-7322 DASH DISASSEMBLY
HYUNDAI AZERA 2006-2010
A
B
C
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Remove (1) Phillips head screw from
bottom right hand corner then unclip
and let the panel below the steering
column hang. (
Figure A)
2
Remove (1) Phillips screw from the
lower left side of the radio panel
behind panel removed in step 2.
(Figure B)
3
Unclip and remove the trim panel
above the radio that extends across
the dash to the passenger side.
(Figure C)
4
To Next Page
