Metra Electronics 95-7417 - 2000-2003 Nissan Maxima Dash Disassembly

95-7417
DASH DISASSEMBLY
2000-2003 NISSAN MAXIMA
11
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unclip and remove the vent/radio trim
panel.
Note: For Bose systems the vent
assembly will be removed without the
trim panel.
1
2
Remove the ashtray insert and (1)
Phillips screw exposed behind.
3
2
4
5
5
5
5
Unclip and remove the shift lever/ash-
tray trim panel.
4
Remove (2) Phillips screws above the
radio and (2) Phillips screws below the
climate control panel then remove the
radio/climate control assembly.
5
