95-7417
DASH DISASSEMBLY
2001-2003 NISSAN PATHFINDER
13
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unclip and remove the vent/clock
assembly.
(Figure A)
1
2
Remove (2) Phillips screws from the top
of the radio trim panel then remove the
panel.
(Figure B)
3
Remove (4) Phillips screws securing
radio.
(Figure C)
4
A
B
C
