Metra Electronics 95-7417 - Kit Assembly; Double DIN Head Unit Provision

14
95-7417
KIT ASSEMBLY
2
A
Attach the factory mounting brackets
and the 95-7417 DDIN trim
plate/bracket assembly to the DDIN
head unit with the screws supplied
with the unit. (
Figure B)
Slide the appropriate bracket into
the trim plate aligning the holes in
the trim plate to the clips on the
bracket. (
Figure A)
1
B
DOUBLE DIN HEAD UNIT PROVISION
