Metra Electronics 95-7417 - Dash Disassembly; 1996-1999 Infiniti I-30 Dash Disassembly

95-7417
1
Disconnect the negative battery
terminal to prevent an accidental
short circuit.
1
Unclip and remove the shift lever
trim panel and remove the (2)
screws exposed.
2
1996-1999 INFINITI I-30
Remove (1) screw to the left of the
ashtray then unclip and remove the
ashtray assembly.
3
Unclip and remove the clock/vent
assembly.
4
Remove (4) screws securing the
radio.
5
DASH DISASSEMBLY
